QD-MUP Dental Air Turbine Handpiece
The QD-MUP Dental Air Turbine Handpiece is designed for efficient, precise and comfortable dental procedures. Its ultra-mini 0.9 mm head with a 100° angle design provides improved operational visibility and greater flexibility during treatment.
The handpiece is constructed with titanium alloy materials, making it approximately 30% lighter than stainless steel while offering good abrasion and scratch resistance. Its ergonomic design and lightweight construction help improve handling and patient comfort during dental procedures.
Key Features
- Ultra-mini 0.9 mm head
- 100° angle design
- Improved operational visibility
- Greater flexibility during procedures
- Enhanced patient comfort
- Quick coupling with one-second connection
- NSK-type quick coupling
- 2/4-hole connection available
- Lightweight titanium alloy construction
- Approximately 30% lighter than stainless steel
- Abrasion and scratch-resistant body
- 4-water spray cooling system
- Push-button chucking system
- Germany ceramic bearings
- Autoclavable up to 135°C
Technical Specifications
| Specification | Details |
|---|---|
| Model | QD-MUP |
| Head Size | 9.2 × H10.8 mm |
| Angle | 100° |
| Air Pressure | 0.2–0.3 MPa |
| Maximum Rotation Speed | 380,000–420,000 rpm |
| Noise | |
| <65 dB | |
| Chucking Type | Push Button |
| Torque | 18W (as shown in source image) |
| Spray | 4-Water Spray |
| Bearings | Germany Ceramic Bearings |
| Body Material | Titanium Alloy |
| Disinfection | Autoclavable, not more than 135°C |
| Connection | 2/4 Holes |
Quick Coupling
The QD-MUP features a quick coupling system designed for one-second connection, supporting convenient installation and removal. The handpiece uses an NSK-type quick coupling and supports 2/4-hole connections.
Lightweight Titanium Alloy Body
The body is made from titanium alloy material, providing a lightweight construction while maintaining durability. According to the supplied product information, the titanium body is approximately 30% lighter than stainless steel and offers abrasion and scratch resistance.
Ultra-Mini Head Design
The 0.9 mm ultra-mini head with a 100° angle is designed to provide improved visibility and flexibility, helping the operator access the treatment area more conveniently.
Water Spray System
The handpiece features a 4-water spray system to support effective cooling during operation.
Sterilization
The product is specified as autoclavable at temperatures up to 135°C. Follow the manufacturer’s sterilization instructions for proper operation and maintenance.
